8 channel DVR - Camera Kit | 2 Infrared domes | 2 infrared bullets | H264 video compression

8 Channel DVR Kit with 2 IR Dome & 2 IR Bullet Cameras

Kit Features

  • P2P Cloud Network
  • Easy Network Connection
  • Mobile Phone Monitoring
  • Playback: 8 CH simultaneously playback
  • USB Mouse Support,
  • PTZ Support
  • Support Multiple Web Users
  • Multiple Search Modes
  • Pentaplex Operation
  • Advanced Digital Zoom
  • On Screen Display Menu

Send Me Prices

Camera:
960H, Bullet, Dome, Infrared
DVRS:
8 Camera, 960H

Get Prices

Price: Login
Points to Purchase:0
Item #: MAX-8KIT
Availability: Discontinued notify me

8 channel DVR - Camera Kit | 2 Infrared domes | 2 infrared bullets | H264 video compression

8 Channel DVR Kit with 2 IR Dome & 2 IR Bullet Cameras

Kit Features

  • P2P Cloud Network
  • Easy Network Connection
  • Mobile Phone Monitoring
  • Playback: 8 CH simultaneously playback
  • USB Mouse Support,
  • PTZ Support
  • Support Multiple Web Users
  • Multiple Search Modes
  • Pentaplex Operation
  • Advanced Digital Zoom
  • On Screen Display Menu

Main Features

  • Maximum Recording Rate REAL TIME 240FPS (8-channel model)
  • Control Mode Front panel, USB mouse, IR remote control, Keyboard, Network
  • Recording Resolution CIF
  • Display Frame Rate REAL TIME 240FPS (8-channel model) with 1/4/8 split
  • Play Back 8CH simultaneously
  • Remote Client software IE browser (Vista & Win7 compatible)
  • Multi-lingual Operating System Yes
  • Operation Modes Simplex/Triplex selectable - simultaneous Monitor record
  • Video Display & Picture Control Yes
  • Video Search Functions VGA Yes
  • VGA Support:1280*1024
  • Backup USB DISK, Network
  • Unique User Optional Boot Screen

  • Compression Standard H.264
  • Video format NTSC
  • Video input 8CH BNC
  • Video output 1CH TV , 1CH VGA
  • Audio input 1CH RCA
  • Audio output 1 RCA connector (mono)
  • HDD Capacity SATA Interface HDDx1
  • External storage External USB devices
  • USB 2 * USB2.0
  • Communication port 1 RS485 serial
  • Performance /System
  • Resourses
  • 8 CIF Real Time Pentaplex: Live recording, Playback,
  • Backup, Remote access, PTZ control, Mobile monitoring
  • Network Interface 1*RJ45,100Mbps Ethernet
  • Network protocols TCP/IP PPPOE DHCP DDNS
  • Pan-Tilt-Zoom 1*RJ485 Support PELCO-D,PELCO-P Procotol
  • Alarm No
  • Mobile phone Support iPhone, Symbian OS, Blackyberry and Android Mobile phone
  • Power 12V/2A (included)
  • Operating Temperature 10°~40°C (50°~104°F)
  • Working environment -10°~+55°/10~90%RH/86~106Kpa
