AHD | TVI | CVI | 5MP & 4MP | 2K HD Camera
This premium quality 4 in 1 outdoor speed dome camera provides users with 5MP 2K AHD, TVI camera technologies. The built-in infrared array provides exceptionally even and consistent long-distance night coverage. A 32 bit processor, with soft ID, more storage space, higher speed, better performance, lower consumption are true assets for your security system. A digital temperature controlling system protects the IR LED Array. The 27x Zoom this speed dome camera will auto adjust zoom according to different distance.
Main Features
- Premium Components
- 5MP 2K Resolution
- 1/3” Progressive Scan CMOS
- 27X Optical Zoom
- Intelligent 3D
- 164 (feet) 60 (meters) IR Range
- Electronic shutter
- 360°endless pan range
- 3 Programmable Pattern groups (Pan / Tilt / Zoom )
- 255 presets
- IP66 Waterproof Metal Housing Casing
- CAMERA*
- Image Sensor: 1/3” CMOS
- Effective Pixels: 5.0 Megapixes
- Min. Illumination: 0.05Lux :Color/0.01 Lux:B/W
- Zoom: 27x, f=4.7mm- 94.mm F1.6 (W)- 2.7(T)
- Day/Night: Auto / Color / BW
- SNR: ≥50dB (AGC OFF)
- WDR: DWDR
- White balance: Auto / Indoor / Outdoor / Manual
- Horizontal Resolution: 5mp / 4mp
- Electronic shutter: 1/30s~1/10,000s
- VIDEO*
- Video Output: 1080P AHD output /1080P TVI output , CVI 1080P
output ,CVBS output
- Connection: BNC & RS-485
- NETWORK*
- Communication Protocol: Pelco D, Pelco P
- Operation OSD language: Chinese /English
- OSD Display: Dome menu & camera menu adjustment
- Camera Menu Operation: Support the operation of camera set up
- INFRARED*
- Luminary: Array Φ20 6pcs
- Night vision distance: 164 (feet) 60 (meters)
- Lamp control: Auto, Manual, by Zoom
- DOME FEATURES*
- CPU Type: 32 bit ARM CPU
- Address: 0~255 (soft address and hard address)
- Pan Range: 360° continued rotation
- Tilt Range: 0~90°(Auto Flip)
- Manual pan speed: 0~120º/S0~120º/S
- Manual tilt speed: 0~90°/S
- Preset points: 255
- Actual preset: Accuracy ±0.10°
- Preset speed: 200°/S
- Home position: Return to preset / scan / pattern / if there is no
command
- Operation recall: Recall operation zone
- Tour: 5
- Intelligent 3D: Scan Auto Pan & Tilt & Zoom /Manual
- Pattern group: 3 Programmable (Pan / Tilt / Zoom )
- Speed adaption: Speed slows down automatically when zoom in
- Auto Scan:
- Non-limited position of manual continued Auto
scan
- Intelligent power
off real time memory:Automatic save functions setting ,automatic
wake up tour function
- GENERAL*
- Power: DC12V±10%; 5A
- Working Temperature; -35°C ~ + 55°C (-31~+131°F)
- Working Humidity:<90% (Non condensing)
- Consumption: < 50W
- Dimensions: 251 x 136 mm
(9.8 ix 5.3 inches)
