H.265 / H.265 | 8MP | 4K
Network Camera | PoE | Dragonfire® IR
Medallion 8MP (4K) IP Outdoor Turret Security Camera with Varifocal 2.8-12mm motorized One lock Auto Focus. Starvis and Exmor technology provides amazing night time shots up to 150ft with Dragonfire® IR array.
Main Features
- Premium Components
- 8MP 3840 (H) × 2160 (V) Resolution
- 1/2.5" Progressive CMOS (8.51M pixels)
- 2.8 ~ 12mm (Motorized) Lens: H.FOV: 87 ~ 28°
- 40pcs (DragonFire® SMD) LEDs Stealth Infrared Cover
- Up to 145 feet (45m) IR Range
- H.265 / H.264 Video Compression
- Auto switching infrared-cut filter (OSD on / off)
- Multiple adjustable Video Streaming
- IEEE 802.3af / IEEE 802.3at | PoE
- IP66 Metal Housing Casing
- Resolution: 8MP 3840 (H) × 2160 (V)
- Image Sensor: 1/2.5" Progressive CMOS (8.51M pixels)
- Min. Illumination: Color 0.1lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
- Shutter Time: Auto/Manual 1/5 ~ 1/20000s
- Shutter Controls: Active Shutter Controls
- Lens: 2.8 ~ 12mm (Motorized) H.FOV: 87 ~ 28°
- F-Stop: F 1.6 ~ 2.9 ±5%
- Day&Night: Auto switching infrared-cut filter (OSD on / off)
- WDR: Digital WDR
- Video Compression: H.265 / H.264
- Video Bit Rate: 8Kbps ~ 8Mbps
- Video Streaming: 3 Individually Adjustable Streams
- Frame Rate:
- Mainstream
8MP (3840x2160),4MP(2592x1520)
3MP(2304x1296),1080P(1920x1080),
720P(1280x720),
- Substeam: 1080P(1920x1080),720P(1280x720),
VGA(640x480),QVGA(320x240)
- Mobilestream: VGA(640x480), QVGA（320x240）
- Image Settings:
- Image rotate, Saturation, Contrast, Hue, Brightness, Sharpness
- BLC: Supported
- ROI: Supported
- Privacy Mask: Supported
- AI Analytics:
- Cross line Detection, Intrusion Detection, Stationary Object Alert, Pedestrian Detection, Face Detection, Cross Counting
- Protocols:
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
- Compatibility: Open compatibility, API, Cortex Plug&Play
- Network Interface: RJ45 10M / 100M Ethernet Interface
- Illumination: 40pcs (DragonFire® SMD) LEDs Stealth Infrared Cover
- IR Range: Up to 145 feet (45m)
- ePTZ: Digital Pan Tilt Zoom
- SD Card: Internal
- Alarm Trigger: Yes, Screw Terminal
- Audio: Yes
- Video Output: Yes
- Reset System: Hardware reset button and software
- PoE: Yes, IEEE 802.3af / IEEE 802.3at
- Casing: Metal housing IP66 Waterproof
- Power Supply: DC 12V / POE
- Storage Temperature: -30~+60°C (-22~+140°F)
- Operating Temperature: -30~+55°C (-22~+131°F)
- Dimension: 135.4 X 127.7mm (5.33 X 5 inches)
- Weight: Approximately 1.59 lbs (720g)
